Product Details
Features
– Premium Material: GB 304 stainless steel sheet metal forming, beautiful, durable, and highly resistant to corrosion.
– Flexible Directional Control: Brake lever steering can be set to one-way or two-way (optional).
– Multiple Control Modes: Supports manual and automatic operation (optional).
– Device Compatibility: Can mount a variety of control devices including metal security gates, IC/ID cards, barcode cards, etc.
– Ultra-Quiet Operation: Utilizes a third-generation silent mechanical design for smooth operation with no noise impact.
– Clear Indicators: Directional design of ultra-bright LED lights to indicate passage clearly and catch the eye.
– Automatic Access: The reader automatically unlocks the brake lever to a certain angle after verification, gently bringing people through.
– Access Memory Function: Remembers the number of consecutive authorized pedestrians and keeps the gate open until all have passed.
– Emergency Drop-Arm: In the event of a power outage, the gate automatically drops the brake lever to facilitate evacuation, fully meeting fire safety requirements (automatic type).
– Remote Control: RS485 interface allows access via computer or TCP to RS485 for remote control of the gates.
– Auto Reset: If a valid card is not swiped within a specified time, the gate automatically resets to the original position, canceling access.
Advantages & Benefits
– Exceptional Durability & Low Maintenance: The SUS304 stainless steel construction ensures a long lifespan and low maintenance costs, with a tested MCBF of 1 million cycles.
– Enhanced Security & Traffic Management: Prevents unauthorized entry with physical barriers and supports anti-tailgating. The intelligent access memory function speeds up group entry.
– Uncompromised Safety: Compliant with fire safety requirements. The auto-drop arm feature ensures smooth, safe evacuation during emergencies. (Security Level: Medium)
– Flexible Integration: Easily integrates with various access control systems (RFID, fingerprint, barcode, etc.) through standard RS485 communication.
– Energy Efficient: Operates on low power consumption (Running: 18W, Standby: 6W) while delivering high throughput (RFID: max 30/minute).
– Customizable Branding: Supports custom colors, remote control options, and customized logos to match your facility’s requirements.
Application Scenarios
– Residential Areas and Apartment Complexes
– Office Buildings and Business Parks
– Government Buildings and Public Institutions
– Factories and Industrial Parks
– Schools and Universities
– Indoor and Outdoor Lobbies and Entrances
Technical Specifications
– Power Requirements: AC 100V to 120V or 200V to 240V, 50/60Hz
– Power Consumption: Running: 18W, Standby: 6W
– Working Temperature: -28 °C to 60 °C
– Working Humidity: 5% to 80% (Non-condensing)
– Speed of Throughput: RFID: Maximum 30/minute, Fingerprint: Maximum 25/minute
– Lane Width: 500-650 mm
– Dimension (L*W*H): 520 * 310 * 1010 mm
– Dimension with Packing (L*W*H): 570 * 365 * 1080 mm
– Net Weight: 36 kg
– Weight with Packing: 50 kg
– LED Indicator: Supports
– Cabinet Material: SUS304 Stainless Steel
– Lid Material: SUS304 Stainless Steel
– Barrier Material: SUS304 Stainless Steel
– Barrier Movement: Rotation
– Emergency Mode: Supports
– Security Level: Medium
– MCBF: 1 million
– Options / Accessories: Counter, SUS316 Cabinet and Lid, Remote Control
– Warranty: 2 years
FAQ
1. Q: What material is this tripod turnstile made of? Is it durable?
A: The housing is made of SUS304 stainless steel with sheet metal forming, offering excellent corrosion resistance and durability. It is suitable for both indoor and outdoor applications, and maintains a good appearance even with long-term use.
2. Q: What happens during a power outage? Does it affect safety?
A: In the event of a power outage, the brake lever will automatically drop to allow free passage, meeting fire safety requirements and ensuring smooth evacuation. Once power is restored, it returns to normal operation.
3. Q: Can it control both entry and exit directions?
A: Yes. The brake lever steering can be set to one-way or two-way (optional). This makes it flexible for different scenarios — for example, entry-only, exit-only, or both directions in the same lane.
4. Q: What is the throughput speed and package weight?
A: The throughput speed is up to 30 people/minute for RFID cards. The packing dimension is 570 * 365 * 1080 mm, and the total gross weight with packing is 50 kg.
5. Q: What is the warranty period?
A: This model comes with a 2-year warranty covering manufacturing defects and motor components.
